[Pre-Order] Wirentech 6.5kW Hybrid Solar Inverter for Home Energy Storage

[Pre-Order] Wirentech 6.5kW Hybrid Solar Inverter for Home Energy Storage

Name: [Pre-Order] Wirentech 6.5kW Hybrid Solar Inverter for Home Energy Storage
Brand: Wirentech
Price: 799.00 USD
Availability: InStock

[More Headroom for 120V Loads] — Deliver up to 6.5kW of continuous pure sine wave output for compatible refrigeration, lighting, networking, room-air-conditioning, outlet, and workshop loads. This is a 120V single-phase inverter, not a 120/240V split-phase model.

[Handle Starting Loads with Confidence] — Use up to 9.75kVA peak power, 10ms typical transfer, and motor-starting capability up to 4HP. Verify running watts and startup surge separately for every appliance or motor.

[Harvest More Solar Energy] — Two 4.5kW PV inputs provide up to 9kW of documented solar input, with a 90–260V MPPT range, 300V maximum VOC, and up to 150A PV charging.

[Match the 48V Battery Platform] — Use a battery system within the inverter's 40–60Vdc input range and listed 44V minimum start voltage. Confirm battery current limits, charging settings, and BMS compatibility before connection. USB and RS485 communication are supported.

[Coordinate Solar Grid and Battery] — Use solar for daytime energy recovery, configure grid charging when required, and store energy for selected loads. Battery capacity, reserve settings, solar production, and load demand determine actual runtime.

[Use the Correct Parallel Version] — Parallel operation is limited to the documented SPI4865M150-300P model for configurations of up to six units. The base model must not be assumed to support parallel operation.

[Install with Verified Protection] — Built-in safeguards address overload, short circuit, PV reverse polarity, AC reverse conditions, overvoltage, and temperature. The 540 × 350 × 120 mm, 40.8 lb wall-mounted inverter requires correct breakers, wiring, grounding, airflow, and professional commissioning. A 5-year limited warranty applies under its terms.

$799.00

Product variants

In stock, ready to ship

Secure payment

Reliable delivery

UPS FedEx DHL

Services & Benefits

Free Shipping

Free shipping is available on eligible products and destinations when shown on the product page or at checkout. Remote-area, freight, customs, or special-handling charges may apply where applicable.

View shipping policy

30-Day Return Window

Products purchased directly from Wirentech may be eligible for return within 30 days of delivery. Items must meet the return conditions, and prior authorization is required. Return shipping or other fees may apply to non-quality-related returns.

View return policy

Ships from Our US Warehouse

Eligible in-stock orders ship from our CA warehouse. Most orders are processed within 1-2 business days and typically arrive within 3-7 business days after shipment. Delivery times are estimates and may vary by destination, carrier schedule, weather, and freight requirements.

View delivery details

10-Year Warranty

Eligible Wirentech lithium batteries are backed by a 10-year limited warranty covering verified defects in materials or workmanship under normal use. Warranty eligibility and available remedies are subject to the product condition, proof of purchase, installation details, and technical review.

View warranty policy

Share:

Share

Pairs well with

Order before today’s Pacific Time cutoff: --:--:--

Ordered Today

Ships 1–2 business days

Delivery 4–9 business days

Weekend orders will be processed the following Monday.

[Pre-Order] Wirentech 6.5kW Hybrid Solar Inverter for Home Energy Storage

$799.00

High Output Inverter

The 6.5kW hybrid inverter provides 120V single-phase pure sine wave output with additional headroom for selected household and workshop loads on a 48V battery platform.

Everyday Load Support

Support compatible 120V loads such as refrigerators, freezers, lights, network equipment, room air conditioners, and tools while excluding appliances that require 240V output.

Dual Solar Inputs

Two 4.5kW PV inputs provide up to 9kW of documented solar input with a 90–260V MPPT range, 300V maximum VOC, 120A maximum AC charging, and 150A maximum PV charging.

Flexible Energy Recovery

Solar, grid, and battery inputs work through one 120V single-phase platform, allowing daytime solar recovery and configured grid charging while battery capacity determines available runtime.

Output Surge Performance

The inverter provides 6.5kW continuous output, 9.75kVA peak power, 10ms typical transfer, motor-starting capability up to 4HP, and at least 91% listed maximum inverter efficiency.

Battery Platform Matching

The inverter uses a 40–60Vdc battery-input range with a 44V minimum start voltage, plus USB and RS485 communication for a correctly configured 48V battery platform.

Integrated Electrical Protection

Manual-documented safeguards address overload, short circuit, PV reverse polarity, AC reverse conditions, overvoltage, and temperature while still requiring correct breakers, fuses, wiring, and installation.

Parallel Model Requirements

Parallel operation is limited to the documented SPI4865M150-300P version for configurations of up to six units; the base version must not be assumed to support parallel operation.

Split Phase Inverter

The 7.2kW hybrid inverter provides 120/240V split-phase output on a 51.2V battery platform for off-grid cabins, water systems, workshops, and selected household loads.

FAQs

What is included with the inverter?

This product describes one Wirentech 6.5kW 120V hybrid inverter. Batteries, solar panels, breakers, disconnects, cables, and other system components are not included unless the exact product listing states otherwise. Confirm the model suffix and included accessories before ordering.

Can this inverter power 240V appliances?

No. This is a 120V single-phase inverter. Do not connect an electric dryer, electric range, central 240V HVAC system, Level 2 EV charger, or another appliance that requires 120/240V split-phase output.

How much continuous and peak power does it provide?

The inverter provides 6.5kW of continuous output and up to 9.75kVA of peak power, with 10ms typical transfer and motor-starting capability up to 4HP under the specified conditions. Verify running watts and starting surge separately for every connected load.

What solar input does the inverter support?

The inverter provides two PV inputs rated at up to 4.5kW each, for up to 9kW of documented PV input. The listed operating window is 90–260V MPPT with a 300V maximum PV open-circuit voltage. These are electrical limits, not a promised battery recharge time.

Which battery platform should be used?

This inverter is designed around a 48V battery platform with a 40–60Vdc input range and a listed 44V minimum start voltage. Verify the battery voltage, BMS communication protocol, charge-current limits, and charging settings before connection.

What charging and communication features are available?

The listed limits are 120A maximum AC charging and 150A maximum PV charging. USB and RS485 communication are supported. Final current settings must also remain within the connected battery manufacturer's limits.

What protection functions does the inverter provide?

Manual-documented safeguards address overload, short circuit, PV reverse polarity, AC reverse conditions, overvoltage, and temperature. These internal features do not replace correctly sized breakers, fuses, disconnects, wiring, grounding, ventilation, or professional installation.

Can multiple 6.5kW inverters operate in parallel?

Parallel support applies only to the documented SPI4865M150-300P model, with configurations of up to six units. Do not assume that the base version supports parallel operation; verify the complete model suffix before ordering and commissioning.

What should I verify before installation?

Verify the 120V output requirement, 48V battery compatibility, PV design, model suffix, conductor size, breaker ratings, airflow, and wall support. The inverter measures 540 × 350 × 120 mm, weighs 18.5 kg or 40.8 lb, and has a listed operating range of -10°C to 55°C. A 5-year limited inverter warranty applies under its terms.
